Building Agents

The Agent Card

The foundation of any Telex agent is its Agent Card, a JSON specification that defines its core properties and capabilities. This agent card, represented as a JSON object, contains vital information on the name, skills, and capabilities of your agent.

When adding your agent to Telex, this JSON object is supplied via a publicly accessible URL generally known as the well-known URL. According to the A2A protocol, the recommended location for an agent's Agent Card is {your_agent_base_url}/.well-known/agent.json, where {your_agent_base_url} is the main web address where your agent is hosted. This well-known URL is where Telex (or any other A2A client) discovers your agent's capabilities and its Agent Card.

Within this Agent Card, the url property specifies the base URL for your agent's A2A service endpoints. This is the address where other agents or services will send actual A2A JSON-RPC requests. The structure of the Agent Card is shown below:

{
  name: string;
  description: string;
  url: string;
  provider: {
    organization: string;
    url: string;
  };
  version: string;
  documentationUrl?: string;
  capabilities: {
    streaming: boolean;
    pushNotifications: boolean;
    stateTransitionHistory: boolean;
  };
  securitySchemes?: {
    [scheme: string]: SecurityScheme
  };
  security?:[{
    [scheme: string]: string[]
    }
  ];
  defaultInputModes: string[];
  defaultOutputModes: string[];
  skills: [
    {
      id: string;
      name: string;
      description: string;
      inputModes: string[];
      outputModes: string[];
      examples: [];
    }
  ];
  supportsAuthenticatedExtendedCard?: boolean;
}

note

Fields suffixed with ? are optional

Sample Structure of an Agent card

{
  "name": "PingPongAgent",
  "description": "An agent that responds 'pong' to 'ping'.",
  "url": "https://your-agent-domain.com/api",
  "version": "1.0.0",
  "provider": {
    "organization": "Example Org.",
    "url": "https://www.example-organization.com"
  },
  "documentationUrl": "https://your-agent-domain.com/docs",
  "capabilities": {
    "streaming": false,
    "pushNotifications": false,
    "stateTransitionHistory": false
  },
  "defaultInputModes": ["text/plain"],
  "defaultOutputModes": ["application/json", "text/plain"],
  "skills": [
    {
      "id": "erig4w9292tb",
      "name": "Ping Response",
      "description": "Responds with 'pong' when given 'ping'.",
      "inputModes": ["text/plain"],
      "outputModes": ["text/plain"],
      "examples": [
        {
          "input": { "parts": [{ "text": "ping", "contentType": "text/plain" }] },
          "output": { "parts": [{ "text": "pong", "contentType": "text/plain" }] }
        }
      ]
    }
  ],
  "supportsAuthenticatedExtendedCard": false
}
